Pce Instruments Coating Thickness Gauge PCE-CT 26FN
Hover to Zoom

Jual Pce Instruments Coating Thickness Gauge PCE-CT 26FN



Spesifikasi Pce Instruments Coating Thickness Gauge PCE-CT 26FN

Pce Instruments Coating Thickness Gauge PCE-CT 26FN

Order no.: PCE-CT 26FN

For iron and non-ferrous substrates / Large measuring range / Rotatable color display / Low weight



The coating thickness gauge PCE-CT 26FN can measure non-destructive coatings (paints, plastics ...) on steel / iron and non-ferrous metals. The coating thickness gauge is ideally suited, for example, to detect accidental damage to the vehicle immediately. But also in the industrial sector, the PCE-CT 26FN coating thickness gauge is used for incoming and outgoing inspection in order to be able to offer consistently consistent product qualities.



The ergonomically shaped coating thickness gauge with integrated probe and very simple operation allows you to quickly determine measurement results with high accuracy. The coating thickness gauge PCE-CT 26FN is designed for measurements of non-magnetic coatings such as lacquer, plastic, chrome, copper, zinc, enamel, etc. on steel and iron, as well as all insulating coatings such as lacquer, plastic, enamel, paper, glass, rubber etc. on copper, aluminum, brass, stainless steel and aluminum.



Application / use:



Simply place the coating thickness gauge u. read the measured value. You can easily measure varnish and paint layers, plastic layers, chrome layers, copper plating, zinc layers, galvanizing, enamel ... on steel, stainless steel, iron and similar materials. Non-ferrous metals (copper, aluminum, brass) and anodized aluminum.

By means of the included standards you can adjust the coating thickness gauge at any time. To do this, the coating thickness gauge must be placed on one of the foils. Please make sure that the meter is seated straight / level.



Features


- Immediately ready to measure
- Wear-resistant sensor
- V-groove for measurement on pipes
- One-handed operation
- ISO calibration optional
- Incl. transport case



Specification

Measuring range

0 ... 1250 μm (0 ... 50 mils)

Resolution

1 μm (0.1 mils)

Accuracy

± (3% + 2 μm) or ± (3% + 0.1 mils)

Smallest measuring surface

5 x 5 mm

Smallest radius of curvature

Convex. 3 mm / concave: 50 mm

Smallest thickness of the base material

Fe: at least 0.5 mm



NFe: at least 0.3 mm

Display

OLED display

Ambient temperature

0 ... 50°C / 32 ... 120°F

Power supply

2 x AAA battery 1.5V

Dimension

100 x 52 x 29 mm / 4 x 2 x 1.1 in

Weight

About 68 g / < 1 lb (without batteries)









Accessories

Re-Calibration for Coating Thickness Meter

Order no.: RE-CAL-CT

Re-Calibration for Coating Thickness Meter

ISO re-calibration incl. certificate for coating thickness meter. This is often required to comply with DIN ISO 9000.

If your calibration certificate expires, you can easily return your meter for re-calibration. We carry out the calibration and send you the device with a new calibration certificate.

Calibration certificates are issued specifically for the customer and are excluded from the right of return

Manufacturer: PCE Instruments

Price excl. VAT &. delivery
2 year Warranty



ISO Calibration Certificate for Coating Thickness Gauge

Order no.: CAL-CT

ISO Calibration Certificate for Coating Thickness Gauge

ISO calibration certificate for coating thickness measuring devices for compliance with DIN ISO 9000.

Calibration certificates are issued specifically for the customer and are excluded from the right of return.

Manufacturer: PCE Instruments



What's In The Box:

1 x Coating thickness gauge PCE-CT 26FN
2 x AAA batteries 1.5V
1 x Set of calibration foils (5 pieces)
1 x Fe standard block
1 x NFe standard block
1 x Transport case
1 x User manual
