Pce Instruments NDT Test Instrument PCE-TG 300
Hover to Zoom

Jual Pce Instruments NDT Test Instrument PCE-TG 300



Spesifikasi Pce Instruments NDT Test Instrument PCE-TG 300

Pce Instruments NDT Test Instrument PCE-TG 300

Order no.: PCE-TG 300

The PCE-TG 300 is a wall NDT test instrument with special sensors for various applications. In general, the wall thicknesses of all homogeneous materials can be measured with the PCE-TG 300. For damping or scattering materials such as plastic or cast a special sensor is available. An angled 90° sensor also enables measurements at hard-to-reach measuring points. The speed of sound can be set freely on the wall NDT test instrument PCE-TG 300 and thus adapted to a wide variety of materials.

The measured values ​​are displayed directly on the easy-to-read TFT color display. Due to the internal memory, which can be read out via the optionally available software, different measuring points can be clearly stored. The non-destructive ultrasound measuring method enables the measurement even on end products. Thanks to the Echo-Echo working mode, even coated workpieces can be measured.



Features

Large measuring range
- Various sensors available
- Battery operation
- Error and voids detection
- Internal measurement data memory
- Print via Bluetooth



Specification

Measuring range

PE: pulse-echo mode 0.65 ... 600 mm (steel)



EE: echo-echo mode 2.50 ... 60 mm

Accuracy

± 0.04 mm H [mm] (<10 mm); ± 0.4% H [mm] (> 10 mm)



H refers to the material thickness of the workpiece

Resolution

0.1 mm / 0.01 mm / 0.001 mm (adjustable)





Measurable materials

Metals



Plastics



Ceramics



Epoxy resin



Glass



And all homogeneous materials





Working modes

Pulse echo mode (fault and blower detection)



Echo-Echo mode (hiding layer thicknesses, eg paints)





Calibration

Sound velocity calibration



Zeroing



Two-point calibration





View mode

Normal mode, Scan mode, Difference mode

Units

mm / inch

Data transfer

Print via Bluetooth / USB 2.0

Storage

Non-volatile memory with 100 data groups with 100 data sets each

Operating time

Continuous operation 100 h



Automatic stand-by mode (adjustable)



Automatic switch-off mode (adjustable)





Power supply

4 x AA battery 1.5V

Display

320 x 240 pixels TFT LCD color display with brightness adjustment

Operating conditions

0 ... 50°C / 32 ... 122°F, ≤ 80% RH not condensing

Storage conditions

-20 ... 70°C / -4 ... 158°F, ≤ 80% rh non-condensing

Dimensions

185 x 97 x 40 mm / 7.3 x 3.8 x 1.6 in

Weight

375 g / < 1 lb





Specification of the available sensors for wall thickness gauge PCE-TG 300





NO2



Frequency

2.5 MHz

Diameter

14 mm

Measuring range

3 ... 40 mm (steel)



3 ... 300 mm (steel)

Minimum diameter of pipes

Not suitable for curved materials

Description

For damping / scattering materials (plastics, cast iron)





NO5



Frequency

5 MHz

Diameter

10 mm

Measuring range

1 ... 600 mm (steel)



Minimum diameter of pipes

20 x 3 mm

Description

Normal measurement





NO5 / 90°



Frequency

5 MHz

Diameter

10

Measuring range

1 ... 600 mm (steel)

Minimum diameter of pipes

20 x 3 mm

Description

Normal measurement





NO7



Frequency

7 MHz

Diameter

6 mm

Measuring range

0.65 ... 200 mm (steel)

Minimum diameter of pipes

15 x 2 mm

Description

Or thin-walled or heavily curved pipes





HT5



Frequency

5 MHz

Diameter

12 mm

Measuring range

1 ... 600 mm (steel)

Minimum diameter of pipes

30 mm

Description

For high temperatures (max 300°C / 572°F)





P5EE



Frequency

5 MHz

Diameter

10 mm

Measuring range

PE: 2 ... 600 mm, EE: 2.5 ... 100 mm

Minimum diameter of pipes

20 x 3 mm

Description

Normal measurement and EE test



Accessories

K-GEL High Temperature Coupling Gel

Order no.: K-gel

K-GEL High Temperature Coupling Gel

The contact gel is used in ultrasonic material thickness measurements. The gel ensures good contact between the measuring head and the workpiece. The high temperature contact gel can be used at temperatures up to 350°C / 662°F.


- Usable up to 350°C / 662°F
- Content: 50 ml

Catalogue: Measuring Instruments / Test Meters / Thickness Gauge

Manufacturer: PCE Instruments



Re-Calibration for Material Thickness Meter

Order no.: RE-CAL-MT

Re-Calibration for Material Thickness Meter

ISO re-calibration incl. certificate for material thickness meter. This is often required to comply with DIN ISO 9000.



- Calibration points are: 5; 10; 20; 50 and 100 mm

If your calibration certificate expires, you can easily return your meter for re-calibration. We carry out the calibration and send you the device with a new calibration certificate.

Calibration certificates are issued specifically for the customer and are excluded from the right of return

Manufacturer: PCE Instruments



ISO Calibration Certificate for Thickness Measurement

Order no.: CAL-MT

ISO Calibration Certificate for Thickness Measurement

ISO calibration certificate for thickness measurement

Manufacturer: PCE Instruments



Ultrasonic Contact Gel (120 ml)

Order no.: TT-GEL

Ultrasonic Contact Gel (120 ml)

Ultrasonic contact gel for use with ultrasonic contact transducers

- Improves contact between the transducer head and the material to be measured
- Protects material surfaces from the transducer head
- 120 ml size
- See downloads for MSDS

Manufacturer: Charles Tennant & Co (Eire) Ltd.



What's In The Box:

1 x NDT test instrument PCE-TG 300
1 x Sensor P5EE
1 x 100 ml coupling gel
1 x Transport case
4 x AA batteries
1 x User manual
